Microphone Preamp |
Type |
XLR female, balanced |
Frequency Response (±3.0 dB) |
10 Hz to 22 kHz |
Input Impedance (Balanced) |
1,32 kΩ |
THD+N (unwtd, 1 kHz @ +4 dBu Output, Unity Gain) |
< 0.005% |
S/N Ratio (Unity Gain, Ref. = +4 dBu, 20 Hz to 22 kHz) |
> 94 dB |
Common Mode Rejection Ratio (1 kHz, 40 dB Gain) |
> 65 dB |
Gain Control Range (± 1 dB) |
0 dB to 40 dB |
Max Input Level (Unity Gain, 1 kHz @ 0.1% THD+N) |
+0 dBu |
Phantom Power (±2 VDC) |
+48 VDC |
Line Input |
Max Input Level (Unity Gain, 1 kHz @ 0.1% THD+N) |
+14 dBu |
Type |
JACK ¼" TRS female, balanced |
Input Impedance |
15 kΩ |
Instrument Input |
Max Input Level (Unity Gain, 1 kHz @ 0.1% THD+N) |
+14 dBu |
Type |
JACK ¼" TS female, unbalanced |
Input Impedance |
1 MΩ |
Line Outputs |
Type |
JACK ¼" TRS female, balanced |
Output Impedance |
600Ω |
Headphone Output |
Type |
JACK ¼" TRS active stereo |
Maximum Output |
50 mW/ch. @ 32Ω Load |
Frequency Response (±1.0 dB) |
10 Hz - 25 kHz |
Digital Audio |
ADC Dynamic Range (A-wtd, 48 kHz Sample Rate) |
107 dB |
DAC Dynamic Range (A-wtd, 48 kHz Sample Rate) |
108 dB |
Bit Depth |
16 / 24 /32 |
Reference Level for 0 dBFS |
+14 dBu |
Internal Sample Frequency Selections (kHz) |
44.1, 48, 88.2, 96, 176.4, 192 |
Power |
USB bus-powered |
Physical |
Height |
52 mm (2.05") |
Depth |
106 mm (4.17") |
Width |
160 mm (6.30") |
Weight |
0.53 kg (1.17 lbs) |
