Proel Sound systems Wireless Microphone U24B (headset)

VendorProel
Share
- WhatsApp
- Deel
- Tweet
- Pin it
- Messenger
- Email

Product form

U24 B 2.4 GHz Wireless Microphone System The U24 USB Wireless Microphones are professional wireless systems offering a high-definition, interference-free... Read more

Model Pickup at our warehouse? Pickup at our warehouse?

SKU: U24B
Barcode: 8032496467151

Pre-order

€180,00€112,50 Excl. VAT

Where to buy?

Find your nearest dealer here

U24 - Receiver
Frequency Range	2.404 – 2.476 GHz
RF Sensitivity	-78 dB
Frequency Response	50 Hz – 15 KHz
Sampling	16 bit @ 38.5KHz
THD	<0.05% @ 1KHz
SN Ratio	>85 dB
Transmission Delay	18.3 mS
Output Connector	USB Type-A
Audio Output Level	4dBu (1000mV)
Current	<55mA
Operating Temperature	-10 °C ~ 50 °C
Dimensions (WxHxD)	94 x 26 x 9.5 mm

WM24B - Bodypack Transmitter
Frequency Range	2.404 – 2.476 GHz
Transmitting Power	< 10 dBm
Transmission Distance	Up to 25m (open space)
Frequency Response	50 Hz – 15 KHz
Sampling	16 bit @ 38.5KHz
THD	<0.05% @ 1KHz
SN Ratio	>85 dB
Transmission Delay	18.3 mS
Input Connector	TA4M
Power Supply Battery	2x1.5V AA alkaline type
Operating time	Up to 20 hours
Dimensions (WxHxD)	62 x 85 x 22 mm

HCM-38 - Headset Microphone
Transducer type	Back-electret plate
Polar pattern	Cardioid
Frequency response	80Hz - 12KHz
Max SPL	110 dB
Nominal Impedance	680 ohm
Power Supply	1.5-3 volt DC, 0.05mA
Cable	1.2 mt
Connector	Mini XLR 4-pin
Weight	51 gr

U24 - Receiver
Frequency Range	2.404 – 2.476 GHz
RF Sensitivity	-78 dB
Frequency Response	50 Hz – 15 KHz
Sampling	16 bit @ 38.5KHz
THD	<0.05% @ 1KHz
SN Ratio	>85 dB
Transmission Delay	18.3 mS
Output Connector	USB Type-A
Audio Output Level	4dBu (1000mV)
Current	<55mA
Operating Temperature	-10 °C ~ 50 °C
Dimensions (WxHxD)	94 x 26 x 9.5 mm

WM24B - Bodypack Transmitter
Frequency Range	2.404 – 2.476 GHz
Transmitting Power	< 10 dBm
Transmission Distance	Up to 25m (open space)
Frequency Response	50 Hz – 15 KHz
Sampling	16 bit @ 38.5KHz
THD	<0.05% @ 1KHz
SN Ratio	>85 dB
Transmission Delay	18.3 mS
Input Connector	TA4M
Power Supply Battery	2x1.5V AA alkaline type
Operating time	Up to 20 hours
Dimensions (WxHxD)	62 x 85 x 22 mm

HCM-38 - Headset Microphone
Transducer type	Back-electret plate
Polar pattern	Cardioid
Frequency response	80Hz - 12KHz
Max SPL	110 dB
Nominal Impedance	680 ohm
Power Supply	1.5-3 volt DC, 0.05mA
Cable	1.2 mt
Connector	Mini XLR 4-pin
Weight	51 gr

U24 B 2.4 GHz Wireless Microphone System

U24 B 2.4 GHz Wireless Microphone System
