Headphone AMP HPAMP106 The 100 Series is a range of D.I. Boxes and Headphone Amps designed to complement audio systems in stage applications, recording studios and fixed installations. Hosted in a stylish extruded and stackable aluminum shell or in a sturdy metal chassis, the 100 Series products are meant to deliver sound quality, versatility and stage-proof reliability in a very affordable package. 6 independent high-power amp sections suitable for any type of headphones 4 selectable main stereo/mono inputs with ¼” JACK connectors (REAR panel) 6 stereo headphone outputs with individual level controls , input selector and ¼” JACK connectors (FRONT panel) 300mW max output level at 32 ohm (per channel) Built-in power supply with toroidal transformer and voltage selector 19” rack mountable metal chassis Technical specs: Input Section   Inputs 4 stereo Input Impedance 47 Kohm Max Input Level +25 dBu Connectors  2 x 1/4" jack unbalanced (each input) Output Section   Outputs 6 stereo Maximum output (2x) 193 mW @ 32 ohm (each) Load Impedance minimum 16 ohm per channel Max gain +13 dB each channel Connector  1/4" jack stereo (each output) System Performance    Distortion (THD) 0.02 % Noise  < -98 dBu unweighted Frequency Response  20 Hz - 20 KHz (-3 dB) General    Controls OUTPUT LEVEL, INPUT SELECTOR Indicators Power ON Power supply Selectable 100-120 VAC, 220-240 VAC, 50-60 Hz Dimensions (W x H x D)  480 x 44 x 210 mm Weight 3,9 Kg

Read more less

Headphone AMP HPAMP104 The 100 Series is a range of D.I. Boxes and Headphone Amps designed to complement audio systems in stage applications, recording studios and fixed installations. Hosted in a stylish extruded and stackable aluminum shell or in a sturdy metal chassis, the 100 Series products are meant to deliver sound quality, versatility and stage-proof reliability in a very affordable package. Very compact and portable package ¼” JACK + RCA stereo/mono input 4 x ¼” JACK stereo headphone outputs with individual level controls +22dB max output level (per channel) 10 ohm minimum output impedance  (per channel) Powered by DC adaptor (included) Technical specs: Input Section   Inputs 1 stereo Input Impedance 500 Kohm Max Input Level +15 dBu Connectors  1/4" jack stereo, 2 x RCA Output Section   Outputs 4 stereo Maximum output (2x) 45mW @ 100 ohm (each) Load Impedance minimum 16 ohm per channel Max gain +20 dB each channel Connector  1/4" jack stereo (each output) System Performance    Distortion (THD) 0.02 % Noise  < -98 dBu unweighted Frequency Response  20 Hz - 20 KHz (-3 dB) General    Controls OUTPUT LEVEL, INPUT STEREO/MONO Indicators Power ON Power supply 12-18 VDC (adapter included) Dimensions (W x H x D)  152 x 50 x 72 mm Weight 0,8 Kg

Read more less
