Proel Sound Wedge series Stage Monitor

WD 15A V2 Active Stage Monitor The WEDGE Series PROEL has set a standard for affordable and road-proof stage monitors, able to offer a highly valuable monitoring solution, with perfect sound intelligibility and high SPL in low-profile and portable enclosures. The Version 2 of this very successful series represents a major step forward, with several design’s refinements and feature’s improvements. The lightweight CLASS D amplifier modules with SMPS have been completely re-designed, to provide the utmost reliability even when the system is stressed at the highest sound pressure levels. Coupled to a sophisticated analog processing, they provide an extremely detailed response, particularly in the vocal range, and a remarkable resistance to feedback. Two tailored EQ PRESETS are available for the use of the speaker not only for stage monitoring (MONITOR), but also as a MAIN SOUND SYSTEM (FOH). The stylish design of the cabinets, with integrated handles, recessed connection panel and pole socket, has been optimized reducing further the profile and, therefore, the footprint on the stage. Knowing very well the mistreatment the stage monitors are usually subjected to, we have greatly improved the strength of the cabinet's polyurethane painting, making them resistant to any abuse. Also the custom designed coaxial transducers, able to provide a perfect HF and LF alignment and a controlled directivity for a perfect listening from any position, have been updated, especially the 10” that features now a compression driver with increased efficiency. The V2 WEDGE monitors are available in three models, offering the perfect solution for any monitoring situations. The ultra-compact WD10AV2 is able to offer a high-performance monitoring also on small stages and it ‘s the ideal solution for speech, vocals and keyboards. WD12AV2, with its high SPL and its full-range response, is the favorite choice for vocals, guitar, horns and electronic instruments or as a high-power monitor for DJs. WD15AV2, with its full extension and powerful and deep response at the low frequencies, is the ideal monitor for bass and drums players. The horn-loaded HF section and the powerful amplifier make it the perfect solution for monitoring also on very large stages. Active 2-way coaxial stage monitor 1” horn-loaded compression driver with 1.35” VC 15” woofer with 3” VC 450 W total power (900 W peak) 400 W class D + 50 W class AB power module with SMPS Dual LIMITER circuit 2 EQ PRESETS for Monitor or FOH (Front-Of-House) use SPL MAX 126 dB Frequency response 45 Hz - 20 KHzLow-profile, lightweight plywood cabinet with black ultra-durable polyurethane paint Reinforced metal grille with dust protection Recessed connection panel for added protection 2 recessed handles for easy transport Pole socket Technical specs: System type 2-way coaxial vented stage monitor Low Frequency Device 15” woofer with 3"VC High Frequency Device 1” compression driver with 1.35"VC Angular Coverage 60° Frequency response 45 Hz - 20 kHz Max SPL at 1mt (peak) 126 dB Amplifier Continuous Power HF: 50 W CLASS AB, LF: 400W CLASS D with SMPS Input Impedance 30 kohm balanced, 15 kohm unbalanced Input Sensitivity 0 dBu Controls LEVEL, PRESET selector (MONITOR, FOH), GND lift Connectors INPUT: COMBO (XLR-F/JACK), LINK: XLR-M Power Supply 230 VAC or 120 VAC - 50/60 Hz Maximum Consumption 575 W Rated Consumption* 300 W Construction Plywood with black anti-scratch polyurethane paint Pole Adapter 1 x side Handles 2 x sides Monitor taper 36° Weight 21 kg (46.3 lb) Dimensions (W x H x D) 600x335x490 mm * Rated consumption is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.

Read more less

FLIGHT CASE FOR TWO PIECES OF WD15AV2 MONITOR

Read more less

Bags for Session Series Padded cover for WD10AV2 Padded cover for WD12V2 Padded cover for WD15V2

Read more less

WD 12A V2 Active Stage Monitor The WEDGE Series PROEL has set a standard for affordable and road-proof stage monitors, able to offer a highly valuable monitoring solution, with perfect sound intelligibility and high SPL in low-profile and portable enclosures. The Version 2 of this very successful series represents a major step forward, with several design’s refinements and feature’s improvements. The lightweight CLASS D amplifier modules with SMPS have been completely re-designed, to provide the utmost reliability even when the system is stressed at the highest sound pressure levels. Coupled to a sophisticated analog processing, they provide an extremely detailed response, particularly in the vocal range, and a remarkable resistance to feedback. Two tailored EQ PRESETS are available for the use of the speaker not only for stage monitoring (MONITOR), but also as a MAIN SOUND SYSTEM (FOH). The stylish design of the cabinets, with integrated handles, recessed connection panel and pole socket, has been optimized reducing further the profile and, therefore, the footprint on the stage. Knowing very well the mistreatment the stage monitors are usually subjected to, we have greatly improved the strength of the cabinet's polyurethane painting, making them resistant to any abuse. Also the custom designed coaxial transducers, able to provide a perfect HF and LF alignment and a controlled directivity for a perfect listening from any position, have been updated, especially the 10” that features now a compression driver with increased efficiency. The V2 WEDGE monitors are available in three models, offering the perfect solution for any monitoring situations. The ultra-compact WD10AV2 is able to offer a high-performance monitoring also on small stages and it ‘s the ideal solution for speech, vocals and keyboards. WD12AV2, with its high SPL and its full-range response, is the favorite choice for vocals, guitar, horns and electronic instruments or as a high-power monitor for DJs. WD15AV2, with its full extension and powerful and deep response at the low frequencies, is the ideal monitor for bass and drums players. The horn-loaded HF section and the powerful amplifier make it the perfect solution for monitoring also on very large stages. Active 2-way coaxial stage monitor 1” compression driver with 1.35” VC 12” woofer with 2.5” VC 350 W total power (700 W peak) 300 W class D + 50 W class AB power module with SMPS Dual LIMITER circuit 2 EQ PRESETS for Monitor or FOH (Front-Of-House) use SPL MAX 124 dB Frequency response 50 Hz - 20 KHz Low-profile, lightweight plywood cabinet with black ultra-durable polyurethane paint Reinforced metal grille with dust protection Recessed connection panel for added protection 2 recessed handles for easy transport Pole socket Technical specs: System type 2-way coaxial vented stage monitor Low Frequency Device 12” woofer with 2.5"VC High Frequency Device 1” compression driver with 1.35"VC Angular Coverage 80° Frequency response 50 Hz - 20 kHz Max SPL at 1mt (peak) 124 dB Amplifier Continuous Power HF: 50 W CLASS AB, LF: 300W CLASS D with SMPS Input Impedance 30 kohm balanced, 15 kohm unbalanced Input Sensitivity 0 dBu Controls LEVEL, PRESET selector (MONITOR, FOH), GND lift Connectors INPUT: COMBO (XLR-F/JACK), LINK: XLR-M Power Supply 230 VAC or 120 VAC - 50/60 Hz Maximum Consumption 445 W Rated Consumption* 235 W Construction Plywood with black anti-scratch polyurethane paint Pole Adapter 1 x side Handles 2 x sides Monitor taper 36° Weight 15 kg (33 lb) Dimensions (W x H x D) 510x310x440 mm * Rated consumption is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.

Read more less

WD 10A V2 Active Stage Monitor The WEDGE Series PROEL has set a standard for affordable and road-proof stage monitors, able to offer a highly valuable monitoring solution, with perfect sound intelligibility and high SPL in low-profile and portable enclosures. The Version 2 of this very successful series represents a major step forward, with several design’s refinements and feature’s improvements. The lightweight CLASS D amplifier modules with SMPS have been completely re-designed, to provide the utmost reliability even when the system is stressed at the highest sound pressure levels. Coupled to a sophisticated analog processing, they provide an extremely detailed response, particularly in the vocal range, and a remarkable resistance to feedback. Two tailored EQ PRESETS are available for the use of the speaker not only for stage monitoring (MONITOR), but also as a MAIN SOUND SYSTEM (FOH). The stylish design of the cabinets, with integrated handles, recessed connection panel and pole socket, has been optimized reducing further the profile and, therefore, the footprint on the stage. Knowing very well the mistreatment the stage monitors are usually subjected to, we have greatly improved the strength of the cabinet's polyurethane painting, making them resistant to any abuse. Also the custom designed coaxial transducers, able to provide a perfect HF and LF alignment and a controlled directivity for a perfect listening from any position, have been updated, especially the 10” that features now a compression driver with increased efficiency. The V2 WEDGE monitors are available in three models, offering the perfect solution for any monitoring situations. The ultra-compact WD10AV2 is able to offer a high-performance monitoring also on small stages and it ‘s the ideal solution for speech, vocals and keyboards. WD12AV2, with its high SPL and its full-range response, is the favorite choice for vocals, guitar, horns and electronic instruments or as a high-power monitor for DJs. WD15AV2, with its full extension and powerful and deep response at the low frequencies, is the ideal monitor for bass and drums players. The horn-loaded HF section and the powerful amplifier make it the perfect solution for monitoring also on very large stages. Active 2-way coaxial stage monitor 1” compression driver with 1” VC 10” woofer with 2” VC 250 W total power (500 W peak) 200 W class D + 50 W class AB power module with SMPS Dual LIMITER circuit 2 EQ PRESETS for Monitor or FOH (Front-Of-House) use SPL MAX 123 dB Frequency response 60 Hz - 20 KHz Low-profile, lightweight plywood cabinet with black ultra-durable polyurethane paint Reinforced metal grille with dust protection Recessed connection panel for added protection 2 recessed handles for easy transport Pole socket   Technical specs: System type 2-way coaxial vented stage monitor Low Frequency Device 10” woofer with 2"VC High Frequency Device 1” compression driver with 1"VC Angular Coverage 80° Frequency response 60 Hz - 20 kHz Max SPL at 1mt (peak) 123 dB Amplifier Continuous Power HF: 50 W CLASS AB, LF: 200W CLASS D with SMPS Input Impedance 30 kohm balanced, 15 kohm unbalanced Input Sensitivity 0 dBu Controls LEVEL, PRESET selector (MONITOR, FOH), GND lift Connectors INPUT: COMBO (XLR-F/JACK), LINK: XLR-M Power Supply 230 VAC or 120 VAC - 50/60 Hz Maximum Consumption 315 W Rated Consumption* 165 W Construction Plywood with black anti-scratch polyurethane paint Pole Adapter 1 x side Handles 2 x sides Monitor taper 36° Weight 12 kg (26,4 lb) Dimensions (W x H x D) 490x265x375 mm * Rated consumption is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.

Read more less
